Blockwright — an Elementor-class visual builder for Payload CMS

Blockwright is an open-source visual website and theme builder for Payload CMS, inspired by the Elementor editing experience. Build complete responsive pages and the theme around them — headers, footers, single and archive layouts, 404s — from widgets, with a structure navigator, reusable templates, a template library, global styling, dynamic Payload data, forms, menus and commerce. All without giving up Payload's developer flexibility: it is a normal plugin, your content stays in your collections, and pages render as React Server Components.

This is not another block list. Payload's built-in Blocks let editors pick from components a developer defined; Blockwright gives them a canvas, layout containers, responsive controls per breakpoint, style controls on every widget, and the ability to build the theme itself. Different problems.

npm install blockwright

import { blockwrightPlugin } from 'blockwright'

export default buildConfig({
  plugins: [blockwrightPlugin({ collections: { pages: { public: true } } })],
})

What's inside

Blockwright
├── Visual canvas ............ drag, drop, select, style, undo/redo, keyboard shortcuts
├── Structure navigator ...... the page as a tree; drag to reorder or reparent
├── Widgets .................. 32 built in, plus your own from the admin or in code
├── Containers / layout ...... flex frames: direction, alignment, gaps, wrapping
├── Responsive controls ...... six breakpoints, per-device values on most settings
├── Theme builder
│   ├── Header
│   ├── Footer
│   ├── Single (page, post, product, any document)
│   ├── Archive and search results
│   └── 404
├── Template library ......... save, browse with live previews, insert, import, export
├── Reusable sections ........ save any section and drop it into other pages
├── Global styling ........... colours, fonts, breakpoints and custom CSS in one place
├── Dynamic Payload data ..... 15 dynamic values bound to fields, docs, site and user
├── Display conditions ....... which template shows where, with include/exclude rules
├── Forms .................... 19 field types, multi-step, logic, notifications, entries
├── Menus .................... nested navigation with dropdowns and a mobile menu
├── Commerce ................. products, price, cart, checkout, product templates
├── PDF templates ............ design how a form entry prints
├── Live preview ............. drafts previewed on the real site before publishing
└── Publishing ............... drafts, publish, and Payload versioning underneath

Why it goes further than it looks

Theme, not just pages	Headers, footers, single and archive layouts and 404s are designed visually, with display rules deciding where each one applies
Design controls	Typography, background, border, radius, shadow, padding, margin, z-index, position, entrance animations and custom CSS per element
Six breakpoints	Widescreen, laptop, tablet landscape, tablet, large mobile and mobile, editable per device
Dynamic content	Bind any text, link or image to Payload fields, the current document, the site or the logged-in user
Extensible	Build widgets in the admin from fields and an HTML template, or register React widgets in code
Compatible	Imports the widely used container JSON format, so existing page-builder templates can be brought over
Fast and accessible	React Server Components, no page JavaScript beyond forms and cart, WCAG 2.1 AA checked in CI

Watch it in action

Click to watch the walkthrough on YouTube.

Status: 0.2.0, early but working. The visual editor, widgets, form builder, menus, commerce widgets, theme and PDF templates, site style and the Payload plugin all work today. Card payments, variant pickers and inline text editing are next. See docs/ROADMAP.md for what is coming next.

Full feature list

Area	Included in this release
Visual editor	Full-screen drag-and-drop editor in the admin: widget panel, Content/Style/Advanced settings, live canvas, desktop/tablet/mobile preview, navigator, undo/redo, keyboard shortcuts, save draft and publish
Library	Saved templates with live previews, "save as template" for any section or page, drag-and-drop JSON import (Blockwright and WordPress page-builder) with a preview, export of the page or the selected element
Structure	Floating, movable page tree (Ctrl+I) with drag-to-reorder
Layout	Frame: flexbox or grid, boxed or full width, responsive direction, gaps, wrapping, columns, semantic tags (section, header, nav…)
Navigation	Menus collection (links to pages follow slug changes, up to three levels) and a Nav menu widget: dropdowns, current-page highlighting, hover effects, and a mobile menu that works without JavaScript
Widgets (32)	Nav menu, Heading, Text, Button, Image, Spacer, Divider, Icon, Icon box, Image box, Icon list, Social icons, Alert, Video (lightweight YouTube/Vimeo/self-hosted), Gallery, Google Maps, Tabs, Accordion (with FAQ schema), Testimonial, Counter, Progress bar, Star rating, Custom HTML, and the commerce and form widgets below
Custom widgets	Build widgets in the admin from fields (or JSON) and an HTML template, see docs/CUSTOM_WIDGETS.md
Forms	Visual field builder with drag-to-reorder and show/hide rules. 19 field types, multi-step with progress indicator, conditional logic, inline validation, spam protection (honeypot, time trap, rate limit), works without JavaScript. Actions: save entry, email notifications (any number, several recipients, HTML or plain-text templates with field placeholders, send-only-when rules, preview), redirect, signed webhook, create a document
Form entries	Readable entry view; PDF templates designed in the visual editor (Entry answers widget and entry placeholders) for print or save as PDF
Styling	Typography, colors, backgrounds and gradients, borders, radius, shadows, spacing — per device (desktop, tablet, mobile, plus optional laptop, widescreen and extra breakpoints)
Site style	Global colors and fonts that every widget can reference, container width, breakpoints, custom CSS
Theme builder	Header, footer, single page, single post, single product, any-document single, archive, search results, 404, reusable section, page template, popup and PDF template types, each shown by display conditions (entire site, front page, a collection, a specific document, exclusions)
Dynamic values	Site name, page title, excerpt, date, any document field, featured image, URL parameters, current user, current date
Commerce	Products, Price, Add to cart, Cart, Cart button and Checkout widgets for @payloadcms/plugin-ecommerce or any products collection, plus visually edited product templates. See docs/COMMERCE.md
Coming soon	Card payments, variant pickers, more widgets, and inline text editing on the canvas
Import	Layouts and templates exported from page-builder style JSON (containers and legacy sections/columns)

Accessibility

Rendered pages target WCAG 2.1 level AA, the standard US ADA guidance points at.

• Semantic markup: landmarks, one h1, real lists, figure/figcaption, fieldset/legend, and labelled form fields.
• Form errors are linked to their field with aria-describedby, marked aria-invalid, and announced politely.
• Menus work with the keyboard, mark the current page with aria-current, and the mobile menu needs no JavaScript.
• Colour and contrast: the default palette and widget styles meet the 4.5:1 text contrast rule.
• Motion: entrance animations and transitions are switched off for visitors who prefer reduced motion.
• Every release runs axe against the demo pages, the form and the 404 page in CI, on desktop and mobile, and fails on any violation.

Your own content still matters: write meaningful alt text, keep heading levels in order, and use the accessible-name fields on icons, menus and videos.

Built for speed and SEO

• Server-rendered. Pages render as React Server Components; the only browser JavaScript Blockwright adds is a small enhancer for forms.
• Minimal CSS. Each page ships only the CSS for widgets it uses, and default values aren't repeated per element.
• No duplicated or blocking styles. Styles are hoisted into <head> once, even when header, page and footer render separately.
• Fast images. Images are lazy by default; the Load first switch prioritises the main image for Largest Contentful Paint. next/image is used automatically.
• Animations without JavaScript. Entrance animations use CSS scroll-driven animations and respect reduced-motion settings.
• Semantic, safe markup. Headings, landmarks, labelled fields, fieldsets and ARIA error messages throughout. Unsafe links are removed, and rich text is cleaned when saved.

Measured on the demo home page (production build): about 30 ms server render once warm, 15 KB of gzipped HTML, and 16 KB of CSS for the whole page.

Requirements

• Node.js 22 (20.9 or newer works)
• pnpm 9: run corepack enable once and pnpm is available
• Docker Desktop, for Postgres and the Mailpit test inbox. You can use your own Postgres 14+ instead.
• Git

Windows: use PowerShell or Git Bash, and enable the WSL 2 backend in Docker Desktop. Wherever this guide says cp, use copy in PowerShell.

Quick start (local testing)

# 1. Get the code and install
git clone https://github.com/wpcoder110/blockwright.git
cd blockwright
corepack enable
pnpm install

# 2. Start Postgres (port 5432) and Mailpit (http://localhost:8025)
pnpm db:up

# 3. Configure the dev app
cp apps/dev/.env.example apps/dev/.env
#    then set PAYLOAD_SECRET in apps/dev/.env to any long random string

# 4. Build the packages and add demo content
pnpm build
pnpm seed

# 5. Run it
pnpm dev

Now open:

URL	What it is
http://localhost:3000	Demo home page (header, hero, grid, contact form, footer)
http://localhost:3000/contact	Multi-step quote form with conditional fields
http://localhost:3000/anything	404 page, rendered from a template
http://localhost:3000/admin	Payload admin. The first visit asks you to create your admin user
http://localhost:8025	Mailpit inbox with every email the forms send

The first request to each page compiles it, so give it a few seconds. After that, pages render in milliseconds.

pnpm seed can be run again at any time; it replaces the demo pages and templates.

First steps in the admin

After you log in, the dashboard shows a Blockwright panel. If the site is empty, click Install demo content.

1. Site style (Blockwright → Site style): change the colors or fonts. Every widget that uses a global color or font updates.
2. Pages: open Home and click Edit with Blockwright in the sidebar. Click any element to edit it, drag widgets from the left panel, switch devices at the top, then Save draft or Publish.
3. Blockwright in the sidebar: an overview of where everything lives, which widgets are available, and how to pause or remove the plugin.
4. Templates: open Site header → Edit with Blockwright → the gear icon to set where it appears (entire site, front page, specific pages, exclusions).
5. Forms: open Request a quote in the editor, select the form, and open Email notifications to change recipients, the HTML message and the send-only-when rules. Preview email shows the result.
6. Form entries: every submission appears as a readable table. Print or save as PDF uses the Entry PDF template, which you can redesign under Templates.
7. Menus: edit Main menu under Blockwright → Menus (links to pages, custom URLs, dropdown items). The header's Nav menu widget shows it; choose another menu in the widget's settings.
8. Custom widgets: create one under Blockwright → Custom widgets; it appears in the editor's widget panel.

Editor shortcuts

Keys	Action
Ctrl+S	Save draft
Ctrl+Z / Ctrl+Shift+Z (or Ctrl+Y)	Undo / redo
Ctrl+D	Duplicate the selected element
Ctrl+I	Show or hide the structure panel
Delete	Delete the selected element
Esc	Leave a field, then deselect

A full manual test checklist is in docs/TESTING.md.

Without Docker

Create a Postgres database called blockwright and put its connection string in DATABASE_URL in apps/dev/.env. Comment out SMTP_HOST to print emails to the terminal instead of sending them to Mailpit.

Common problems

Problem	Fix
ECONNREFUSED 127.0.0.1:5432	Postgres is not running. Run pnpm db:up and check docker ps.
Error: missing secret key	Set PAYLOAD_SECRET in apps/dev/.env.
Port 5432 already in use	Another Postgres is running. Stop it, or change the port in docker-compose.yml and DATABASE_URL.
Changes in packages/* not showing	pnpm dev rebuilds packages on save; if it was stopped, run pnpm build again.
Admin shows an import map error	Run pnpm --filter dev generate:importmap.
Images show in the admin but not on the site ("The requested resource isn't a valid image")	Your upload collection is readable only by logged-in users, which is Payload's default. Add access: { read: () => true } to it. Blockwright warns about this on the dashboard.
Images do not load in Next.js	Payload adds a ?<updatedAt> cache tag to upload URLs; Blockwright strips it for the image optimiser. If you use a storage adapter with a different domain, add it to images.remotePatterns in next.config.ts.
No Create new button on Custom widgets, or no Products button with the ecommerce plugin	Your account needs the admin role. See docs/PERMISSIONS.md.
Home page shows "Page not found"	Run pnpm seed, or create a page with the slug home and publish it.
"Too many submissions" while testing forms	Raise FORMS_RATE_LIMIT in apps/dev/.env (default 10 per minute).

Scripts

Run from the repository root.

Command	What it does
pnpm dev	Watches all packages and runs the dev site on port 3000
pnpm build	Builds all @blockwright/* packages
pnpm build:all	Builds the packages and the dev site
pnpm test	Unit tests for every package
pnpm typecheck	TypeScript checks for every package and the dev site
pnpm seed	Adds or refreshes the demo content (also available as a button on the admin dashboard)
pnpm pack:local	Builds and packs every package into release/ for installing in another project
pnpm db:up / pnpm db:down	Starts or stops Postgres and Mailpit
pnpm --filter dev test:e2e	Browser tests with Playwright (editor tests need SEED_ADMIN_EMAIL and SEED_ADMIN_PASSWORD set when seeding and testing). Run pnpm --filter dev build first, and pnpm --filter dev exec playwright install chromium once

Add Blockwright to your own Payload project

Step-by-step for Windows and the Payload plugin template: docs/INSTALL-EXISTING-PROJECT.md. It is tested end to end with npm.

Blockwright ships as one package, like the official Payload plugins:

pnpm add blockwright

To try unreleased work from this repository instead, run pnpm pack:local and install the files from release/ (see docs/RELEASING.md).

1. Register the plugin in payload.config.ts:

import { blockwrightPlugin } from 'blockwright'

export default buildConfig({
  // ...
  plugins: [
    blockwrightPlugin({
      // a list of slugs, or options per collection
      collections: {
        pages: { public: true }, // adds "View page" and Payload's preview button
        posts: { public: true, url: (doc) => `/blog/${doc.slug}` },
        banners: true, // no public URL, so no View button
      },
      forms: {
        defaultToEmail: 'owner@example.com',
        defaultFromEmail: 'website@example.com',
        allowedCollections: ['leads'], // for the "Create document" action
      },
    }),
  ],
})

The plugin adds:

• a layout field to those collections;
• the Templates and Form entries collections, and the Site style global;
• the POST /api/bw/forms/submit endpoint;
• the visual editor at /admin/blockwright/edit/<collection>/<id>, with an Edit with Blockwright button on each document;
• the dashboard panel.

Then run payload generate:types and payload generate:importmap. Forms send email through the email adapter configured in Payload.

2. Render pages in your Next.js route:

import { BlockwrightDocument, BlockwrightLocation, findDocumentBySlug, singularTheme } from 'blockwright/next'

export default async function Page({ params, searchParams }) {
  const payload = await getPayload({ config })
  const slug = (await params).slug?.join('/') ?? 'home'
  const doc = await findDocumentBySlug({ payload, collection: 'pages', slug })
  if (!doc) notFound()

  const request = { path: `/${slug}`, searchParams: await searchParams }
  const theme = singularTheme('pages', doc, { isFront: slug === 'home' })

  return (
    <>
      <BlockwrightLocation payload={payload} request={request} theme={theme} location="header" />
      <BlockwrightDocument payload={payload} request={request} collection="pages" doc={doc} />
      <BlockwrightLocation payload={payload} request={request} theme={theme} location="footer" />
    </>
  )
}

apps/dev/src/app/(frontend) is a complete, working example, including drafts, preview and the 404 page.

Plugin options

Options follow the conventions of the official Payload plugins: disabled, per-collection settings, and …Overrides to change any generated collection.

Option	Default	Purpose
collections	['pages']	Collections that get the layout field. Per collection: public, url(doc), field
disabled	false	Keeps the schema but skips hooks, endpoints and admin components
templatesOverrides, formEntriesOverrides, menusOverrides, widgetsOverrides, siteStyleOverrides	—	Change a generated collection or global, including fields({ defaultFields })
elements / tags	—	Register your own widgets and dynamic values
templates.slug	bw-templates	Slug of the templates collection
kit.slug	bw-site-style	Slug of the site style global
forms.submissionsSlug	bw-form-entries	Slug of the form entries collection
forms.defaultToEmail / defaultFromEmail / defaultFromName	—	Email defaults
forms.allowedCollections	[]	Collections the "Create document" action may write to
forms.webhookSecret	—	Adds an X-Blockwright-Signature: sha256=… header to webhooks
forms.rateLimit	10 per minute	{ max, windowMs }, or false to disable
forms.storeIp	false	Save visitor IP addresses with entries
canUseUnfilteredHtml	admin users	Who may save Custom HTML and custom CSS
onChange	—	Called when templates, the site style or pages change (for cache revalidation)
uploadCollection	media	Upload collection used for images
adminGroup	Blockwright	Admin sidebar group

Repository structure

apps/
  dev/                 Payload 3 + Next.js 16 test site on Postgres (seed script, e2e tests)
packages/
  editor/              Visual drag-and-drop editor (client React app)
  schema/              Layout JSON format, validation, import upgrades, display conditions
  core/                Controls, widget registry, CSS compiler, site style, dynamic values, templates
  renderer/            React renderer (Server Components) and style hoisting
  widgets-basic/       Frame, Heading, Text, Button, Image, Spacer, Divider, Custom HTML
  forms/               Form widget, shared validation, browser enhancer, server actions
  payload-plugin/      Payload plugin: fields, collections, site style, endpoints, dashboard
  next/                Next.js helpers: document and template rendering, next/image and next/link
docs/
  COMMERCE.md          Shop pages, cart, checkout and product templates
  ROADMAP.md           What is shipped and what is next
  TESTING.md           Manual test checklist for localhost
  LAYOUT_FORMAT.md     The layout JSON format, for editing layouts by hand
  CUSTOM_WIDGETS.md    Building widgets in the admin
  PERMISSIONS.md       Who can edit what, and the admin role
  INSTALL-EXISTING-PROJECT.md  Adding Blockwright to your own Payload project (Windows)
examples/
  existing-project/    Files to copy into an existing Payload project

Layout format

Layouts are stored as JSON in the same shape as the container export format used by popular WordPress page builders, so existing templates and HTML-to-JSON converters work. A minimal page:

[
  {
    "id": "a1b2c3d",
    "elType": "container",
    "settings": { "flex_direction": "row", "flex_direction_mobile": "column" },
    "elements": [
      {
        "id": "e4f5a6b",
        "elType": "widget",
        "widgetType": "heading",
        "settings": { "title": "Hello", "header_size": "h1", "__globals__": { "title_color": "globals/colors?id=primary" } },
        "elements": []
      }
    ]
  }
]

See docs/LAYOUT_FORMAT.md for every widget's main settings, responsive keys, global colors and fonts, and dynamic values.

Contributing

1. Create a branch from main: feat/…, fix/… or docs/….
2. Run pnpm build && pnpm typecheck && pnpm test before pushing.
3. Open a pull request. CI runs the unit tests and the full browser tests against Postgres.

Blockwright supports the widely used container JSON format so existing templates import, but contains no third-party code, icons or text. Please keep it that way.

Licence

MIT © Ahmer Hassan and Blockwright contributors. Product names mentioned here belong to their owners; Blockwright is not affiliated with them.

---

Keywords: payload, payload-plugin, payload cms plugin, payloadcms, page builder, website builder, visual editor, drag and drop builder, block editor, form builder, theme builder, ecommerce, next.js, react, typescript, headless CMS, no-code, landing page builder, elementor alternative for payload.
