CockroachDB Workload Analyzer

An interactive offline analysis tool for CockroachDB workload-exporter zips. The binary is named workload-analyzer.

Point it at a zip file, and a browser opens with 26 preloaded diagnostic queries and a free SQL editor backed by DuckDB; no database server, no cloud, no data leaves your machine.

^{Watch as MP4· recorded from the movr sample export}

Install

Grab a prebuilt binary from the latest release (macOS arm64, Linux x86-64), verify the checksum, and run it:

tar -xzf workload-analyzer_*_darwin_arm64.tar.gz
# macOS only, first run: clear the quarantine attribute
xattr -d com.apple.quarantine ./workload-analyzer 2>/dev/null || true
./workload-analyzer path/to/export.zip

No runtime dependencies. The binary is self-contained. Or build from source.

Overview

workload-analyzer 2025-05-29-cutover.zip
# → extracts zip to temp dir
# → loads CSVs into in-memory DuckDB (large files load in background)
# → opens http://localhost:8080 in your browser
# → Ctrl-C to stop, temp dir is cleaned up automatically

The tool ships as a single binary. The React frontend is embedded via go:embed, so nothing extra needs to be installed to run it.

Interface

Three tabs:

Tab	What it does
Analysis	Click any of the 26 preloaded queries in the sidebar — results appear immediately. Click a fingerprint_id to open a resizable drawer with the query text and per-statement stats (transactions resolve to their constituent statements), with a button to copy the contents.
SQL	Free-form DuckDB SQL editor (Monaco). Press Cmd+Enter / Ctrl+Enter to run.
Schema	Raw DDL from the export's .schema.txt files, one database per dropdown.

Any result grid (Analysis or SQL) sorts client-side: click a column header to cycle ascending → descending → original order. Numeric columns (including bigint/decimal values the export ships as strings) sort numerically, other columns lexically, and NULLs always sort last. CSV/JSON export reflects the current sorted order.

The UI is keyboard-navigable: 1/2/3 switch tabs, j/k step through the query list (arrow keys work when the tab bar or list has focus), and ? opens a dialog listing every shortcut.

Preloaded queries

Category	Query
Statements	Slowest by Mean Latency
Statements	Top CPU Consumers
Statements	Full Table Scans
Statements	Index Recommendations
Statements	High Error Rates
Statements	High Contention Time
Statements	Memory & Disk Spill
Statements	Admission Control Wait
Statements	Plan Instability
Statements	Top Index Recommendations
Statements	Rows-Read Amplification
Statements	Latency Decomposition
Statements	Latency Percentiles by App
Transactions	Slowest by Service Latency
Transactions	High Retry Rates
Transactions	Slow Commit Latency
Transactions	Transaction Statement Breakdown
Transactions	Contention Hotspots
Indexes	Unused Indexes
Indexes	Rarely Used Indexes
Indexes	Table Statistics Audit
Indexes	Stale Table Statistics
Cluster	Non-Default Cluster Settings
Cluster	Node CPU & Memory
Cluster	Non-Default Settings (System VC)
Cluster	Persisted System Settings

All queries use DuckDB JSON path extraction against the CSV files in the export; they run entirely in-process, no network calls.

Getting a workload export

Use the cockroach workload-exporter tool:

export COCKROACH_URL="postgresql://<user>:<pass>@<host>:<port>/<db>?<ssl_opts>"

workload-exporter export \
  --start "$(date -u -v-8H +%Y-%m-%dT%H:%M:%SZ)" \
  --end   "$(date -u -v-30M +%Y-%m-%dT%H:%M:%SZ)" \
  --output-file "$(date +%Y-%m-%d)-export.zip"

The --end offset of 30 minutes accounts for sql.stats.flush.interval (default 10 min) — the most recent window may not have flushed yet.

Architecture

workload-analyzer <zip>
  ├── Extract zip → OS temp dir (removed on exit)
  ├── Parse metadata.json + *.schema.txt
  ├── Load CSVs into in-memory DuckDB
  │     small tables first → statement_statistics.csv last (~1 GB)
  │     HTTP server starts immediately; UI shows a progress bar while loading
  └── Serve embedded React SPA at http://localhost:<port>

Binary layout:
  main.go          CLI entry point, signal handling, server lifecycle
  static.go        go:embed of web/dist → SPA file server with index.html fallback
  internal/
    loader/        zip extraction, DuckDB open/load, metadata/schema parsing
    catalog/       26 preloaded Query structs with verified DuckDB SQL
    api/           6 read-only HTTP endpoints (status, meta, queries, run, schema, databases)
  web/             React + Vite + TypeScript source
    src/api.ts     typed fetch wrappers
    src/hooks/     useStatus (polling), useRun (SQL execution)
    src/components/ LoadingScreen, ResultsTable, QueryList, tab components

Key design choices:

• Native DuckDB (github.com/marcboeker/go-duckdb via CGo) — avoids WASM memory limits, reads CSVs directly with read_csv_auto.
• Progressive loading — the server starts as soon as the zip is extracted; the large statement_statistics.csv loads last in a background goroutine. The UI polls /api/status and shows progress.
• Single binary — go:embed all:web/dist bundles the compiled SPA. One file to distribute, no runtime dependencies.
• Read-only — once loaded, the export database is reopened in DuckDB's read-only mode, so the engine itself refuses any statement that would change it. The tool never writes back to any cluster.

Security & trust model

The tool runs locally, on your own machine, against your own export. The free-form SQL tab executes arbitrary DuckDB SQL by design, so several guards keep that scoped:

• Loopback only — the HTTP server binds to 127.0.0.1, so /api/run is not reachable from the network.
• Cross-site requests refused — loopback binding alone doesn't stop your own browser: any website you visit can fire cross-origin requests at http://localhost:<port>. The server rejects requests whose Origin is not a loopback origin (CSRF) and requests whose Host header is not a loopback name (DNS rebinding).
• Read-only after load — the export is loaded into a DuckDB database file in the same per-run temp directory as the extracted CSVs. Once loading completes, that file is closed and reopened with access_mode=read_only, so DuckDB itself rejects DROP, INSERT, UPDATE, ALTER, CREATE, ATTACH and every other statement that would change the export — this is enforced by the engine, not by filtering SQL text. Scratch CREATE TEMP TABLEs are still allowed; they live outside the export and vanish with the session. (DuckDB can't switch a running database to read-only and won't open an in-memory one read-only at all, which is why the export lives in a file rather than in memory.)
• No file access after load — at the same time, DuckDB's enable_external_access is switched off (a one-way switch DuckDB won't let a query re-enable) and the configuration is locked with lock_configuration, so no setting can be changed from SQL afterwards. The SQL editor can run arbitrary read-only SQL over the loaded tables, but can't read other files on disk via read_csv/COPY/ATTACH. Free-form SQL is refused until this lockdown is in place — "ready" means loaded, read-only and hardened — so there is no window where user-supplied SQL runs with write or file access.
• Local & ephemeral — nothing is written back to any cluster; the extracted CSVs and the DuckDB file live only in a temp directory that is removed on exit.

Prerequisites

To run the binary: nothing (the binary is self-contained).

To build from source:

• Go 1.24+ with CGo enabled (requires a C compiler — gcc or clang). go.mod pins toolchain go1.26.6, which the Go toolchain fetches automatically.
• Node.js 18+ and npm (to build the React frontend)

On macOS: brew install go gcc node

On Linux (Debian/Ubuntu): apt install golang gcc nodejs npm

Building

git clone <this-repo>
cd workload-analyzer
make build

This runs npm install && npm run build in web/, then CGO_ENABLED=1 go build -o workload-analyzer ..

The resulting workload-analyzer binary is self-contained — copy it anywhere and run it.

Running

./workload-analyzer path/to/export.zip

# Custom port:
./workload-analyzer --port 9090 path/to/export.zip

# Print version:
./workload-analyzer --version

A browser window opens automatically. On Linux servers without a display, open http://localhost:<port> manually.

Queries against a table your export doesn't include (e.g. node_cpu_mem / gossip_nodes are absent from application-virtual-cluster exports) return a plain "not in this export" message instead of a raw error.

Development

# Run all tests
make test

# Backend only
CGO_ENABLED=1 go test ./...

# Frontend only
cd web && npm test -- --run

# Integration test against a real export
CGO_ENABLED=1 go test -tags integration -v -run TestIntegration -timeout 10m

# Hot-reload frontend (proxies /api to a running backend)
./workload-analyzer path/to/export.zip &
cd web && npm run dev          # → http://localhost:5173

API

The backend exposes six read-only JSON endpoints:

Endpoint	Description
GET /api/status	Loading state, progress (0–1), per-table status
GET /api/meta	Cluster version, org, export time range
GET /api/queries	Catalog of 26 query descriptors (add ?full=1 to include SQL)
POST /api/run	Execute arbitrary DuckDB SQL ({"sql":"..."}) or a catalog query ({"query_id":"...","db":"..."})
GET /api/schema	Raw DDL text, keyed by database name
GET /api/databases	Distinct database names in the statement stats (for the filter picker)

DuckDB table names

The following tables are available in the SQL editor:

Table	Source CSV
stmt_stats	crdb_internal.statement_statistics.csv
txn_stats	crdb_internal.transaction_statistics.csv
txn_contention	crdb_internal.transaction_contention_events.csv
idx_usage	crdb_internal.index_usage_statistics.csv
table_indexes	crdb_internal.table_indexes.csv
cluster_settings	crdb_internal.cluster_settings.csv
table_stats	system.table_statistics.csv
node_cpu_mem	crdb_internal.node_cpu_mem.csv

Acknowledgements

This tool builds on work by Cockroach Labs:

• It reads exports produced by the workload-exporter tool.
• It was inspired by ziplook.
• Most of the preloaded diagnostic queries are adapted from cockroachdb-skills, which is likewise Apache 2.0 licensed.

License

Licensed under the Apache License, Version 2.0. See NOTICE for attributions.
